Tire pressure monitoring systems
Pulse Mining panel is a key component of our tire pressure monitoring system, designed to automatically receive and process radio pressure sensors data, display important messages and general information on tire performance on the built-in display.
The panel supports configuration of the vehicle wheel arrangement, adding / removing pressure transmitters, setting the threshold of measured values, for which the warning indication should be used).
General specifications
| Operating voltage range | 8 – 32 V |
| Power consumption | 20 W |
Dimensions
| Size (length / width / height) | 135х35х82 mm |
| Display size | 3,37” |
Communication and interfaces
| WIFI | |
| GSM/GPRS | |
| CAN (J1939) interface | 1 |
| RS232 support | |
| GPS | |
Module operating conditions
| Water/dust protection (GOST 14254-2015) | IP67 |
| Operating ambient temperature | -40…+65 °С |
- The panel collects data about the position of the machine (GPS) and vehicle data from the CAN bus.
- The collected data is accumulated in Pulse Mining’s memory.
- Data transmission to the Wialon server online via GSM.
- The transmitted data is processed in the Wialon environment and used for analysis.
